Hastelloy N (UNS N10003)
Corrosion-resistant alloy

Hastelloy N (UNS N10003)
Features
  • HASTELLOY N boasts high creep and oxidation resistance. It can also endure high temperatures and maintain good condition under severe mechanical stress. Between the temperatures of 705-870℃, the alloy is resistant to fluoride salts and oxidation.
  • The material is capable of functioning at extremely high temperatures and under considerable mechanical stress as well as where high surface stability is a requirement.
Chemical Analysis
% Ni C Cr Fe Mo W Cu Al+Ti V B Co Mn P
Hastelloy N Min. Balance 0.04 6 - 15
Max. Balance 0.08 8 5 18 0.5 0.35 0.5 0.5 0.01 0.20 1 0.015
Physical Properties
Density Melting Range Electrical Resistivity Coefficient of Expansion Thermal Conductivity Specific Heat Capacity
8.896 1300-1400℃ 1.20 (20℃) 1.26 (705℃) 1.24 (815℃) 11.6X10-6 11.5 419
Standards
Bar Forging Part Plate, Coil, Sheet
ASTM B573 ASTM B573 ASTM B434
- - -
ASME SB573 ASME SB573 ASME SB434
  • Applications
    Hastelloy N (UNS N10003)
    • Chemical process equipment
