Hastelloy C-2000 (UNS N06200/NICR23M016CU)
Corrosion-resistant alloy

Hastelloy C-2000 (UNS N06200/NICR23M016CU)
Features
  • Hastelloy C-2000 is a material specially designed for resistance to an extensive range of corrosive chemicals including sulfuric, hydrochloric, and hydrofluoric acids over a large temperature range.
  • Resistance to stress corrosion cracking
  • The combination of Molybdenum (16%) and Copper (1. 6%) provide excellent corrosion resistance to reducing media
  • Good oxidizing resistance
Product Form
Bar Plate Seamless Pipe Welded Pipe Seamless Pipe Forging Parts
ASTM B574 ASTM B575 ASTM B622 ASTM B619 ASTM B626 ASTM B564
Chemical Analysis
% Ni Cu Fe Mn C Si S Cr Al Mo P Co
C-2000 Min. Balance 1.3 - - - - - 22 - 15 - -
Max. Balance 1.9 3 0.5 0. 01 0. 06 0. 01 24 0.5 17 0.025 2
Physical Properties
Density 8.9G/CM3
Melting Range 1335-1380℃
The Min. Mechanical Properties under Room Temperature
Alloy Tensile Strength Yield Strength Elongation
RM N/MM2 RP0.2 N/MM2 A5%
HASTELLOY C-2000 690 283 45
  • Applications
    Hastelloy C-2000 (UNS N06200/NICR23M016CU)
    • Chemical Processing
