INCONEL 601 (UNS N06601)
High-temperature alloy
Features
- This alloy is resistant to high temperature oxidation, avoiding oxidation up to 1204℃.
- Inconel 601 alloy has good high temperature strength, and retains its ductility even after long periods of exposure to heat.
- Highly resistant to carburization
- Good creep rupture strength
- Excellent mechanical properties at both room temperature and high temperature
- Metallurgical stability
Chemical Analysis
% | Ni | Cr | C | Mn | Fe | Si | Cu | P | Al | S | |
UNS N06601 | Min. | Balance | 21 | - | - | 10 | - | - | - | 1 | - |
Max. | Balance | 25 | 0. 1 | 1 | 15 | 0. 5 | 1 | 0. 03 | 1.7 | 0. 015 |
Physical Properties
Density | 8.1G/CM3 |
Melting Range | 1320-137°C |
The Min. Mechanical Properties under Room Temperature
Alloy | Tensile Strength | Yield Strength | Elongation | Brinell Hardness |
RM N/MM2 | RPO.2 N/MM2 | A5% | HB | |
Annealing | 650 | 300 | 30 | - |
Solution Treatment | 600 | 240 | 30 | ≤220 |
-
Applications
- Chemical Processing
- Radiant tubes
- Power generation
- Heat treating industry
-
