Inconel 625 (UNS N06625/W.NR.2.4856)
High-temperature alloy
Features
- Inconel 625 is a corrosion and oxidation resistant nickel-based alloy that provides high strength and withstands aqueous environments.
- Inconel 625 has excellent fatigue strength and stress-corrosion cracking resistance when exposed to chloride ions
- This nickel alloy has excellent weldability
- When the temperature reaches 40℃, it will resist corrosion caused by any high concentration of hydrochloric acid solution
Chemical Analysis
% | Ni | Cr | Mo | Nb | Ti | Co | C | Mn | Fe | Si | Cu | P | s | |
UNS N06625 | Min. | Balance | 20 | 8 | 3.15 | |||||||||
Max. | Balance | 23 | 10 | 4.15 | 5 | 0.4 | 0.4 | 0.1 | 0.5 | 0.5 | 1 | 0.015 | 0.015 |
Physical Properties
Density | 8.4G/CM3 |
Melting Range | 1290-1350℃ |
The Min. Mechanical Properties under Room Temperature
Alloy | Tensile Strength | Yield Strength | Elongation | Brinell Hardness |
RM N/MM2 | RPO.2 N/MM2 | A5% | HB | |
Solution Treatment | 760 | 345 | 30 | ≤220 |
-
Applications
- Furnace hardware
- Chemical plant hardware
- Gas turbine engine ducting
- Heat shields
- Jet engine exhaust systems
- Aircraft ducting systems
-
