Incoloy 926 (UNS N08926)
Corrosion-resistant alloy

Incoloy 926 (UNS N08926)
Features
  • Outstanding resistance to chloride-induced stress corrosion
  • Very good corrosion resistance when in contact with oxidizing and reducing media
  • The combination of molybdenum (approximately 6.5%) and nitrogen (approximately 0.2%) in its composition resists pitting and crevice corrosion
Chemical Analysis
% Ni Cr C Mn Fe Si Cu Mo N Ti P S
Incoloy 926 Min. 24 19 - - Balance - 0.5 6 0.15 0.6 - -
Max. 26 21 0. 02 2 Balance 0.5 1.5 7 0.25 1.2 0.03 0. 01
Physical Properties
Density 8.1G/CM3
Melting Range 1320-1390°C
The Min. Mechanical Properties under Room Temperature
Alloy Tensile Strength Yield Strength Elongation
RM N/MM2 RPO.2 N/MM2 A5%
926 650 295 ≤35
  • Applications
    Incoloy 926 (UNS N08926)
    • Seawater environments
    • Heat exchangers, tank housings
    • Distributor systems for sulfuric acid
    • Condenser pipes
    • Pump lines in oil and gas extraction
