Inconel 600 (UNS N06600)
Corrosion-resistant alloy / High-temperature alloy
Features
- Inconel 600 is a nickel-based alloy that features resistance to corrosion and high temperature. It can be formed easily.
- Non-magnetic
- Virtually immune to chlorine ion stress corrosion cracking
- Excellent mechanical properties
Chemical Analysis
% | Ni | Cr | C | Mn | Fe | Si | Cu | P | S | |
UNS N06600 | Min. | 72 | 14 | - | - | 6 | - | - | - | - |
Max. | - | 17 | 0. 15 | 1 | 10 | 0. 5 | 0. 5 | 0. 015 | 0. 015 |
Physical Properties
Density | 8.4G/CM3 |
Melting Range | 1370-1425°C |
The Min. Mechanical Properties under Room Temperature
Alloy | Tensile Strength | Yield Strength | Elongation | Brinell Hardness |
RM N/MM2 | RP0.2 N/MM2 | A5% | HB | |
Annealing | 550 | 240 | 30 | S195 |
Solution Treatment | 500 | 180 | 35 | 5185 |
-
Applications
- Gas turbine components
- Pulp and paper industry
- Aerospace
- Nuclear engineering
- Reactor vessels and heat exchanger tubing
-
